Extruder ProSeries 900
Extruder ProSeries 900
| Product code: ID900S |
The heavy-duty Aluminum Inversion Drum for professional use. The Extruder ProSeries 900 is our largest Inversion Drum mounted on a trolley.
Suitable for air, steam, hot water, and UV installations.
Suitable for air, steam, hot water, and UV installations.
TECHNICAL FEATURES
Range DN50 - DN300 (2''- 12'')
8'' Storz Coupling
Height 1300 mm (51''), width 680 mm (27'')
130° adjustable angle
Integrated pressure gauge
Service window + sight glass
Connector for hot water installations & drain valve
Quick adjustment of the angle
Lockable front wheels
Carrying handles also on the front
The trolley is equipped with a Storz spanner
CAPACITY (4 mm liner):
DN50 - 115 m (2'' - 377 ft)
DN70 - 95 m (3'' - 311 ft)
DN100 - 75 m (4'' - 246 ft)
DN150 - 58 m (6'' - 190 ft)
DN200 - 50 m (8'' - 164 ft)
Made in the EU
