Small and compact minCord cameras are designed to reach even the most difficult-to-reach places.
The non-destructively inspection enables you to inspect even the tightest spaces and save costly disassembles.
Tubes, cavities, welding seams, turbines, hollow profiles, and castings: the camera head with only 13 mm diameter inspects these easily.
At the same time, the cameras are so robust that they can easily withstand harsh field conditions. In this way, you locate all surface damages, cracks, sediments, and deteriorations with minimal effort.

TECHNICAL SPECIFICATIONS
- Pipe diameter between 15 up to 80 mm
- 15 m / Ø 5 mm push-pull cable
- Colour camera stainless steel head KK13; 13 mm diameter, high resolution PAL; multifrequenzy sonde, 512 Hz and 33 kHz
- Axial camera
- Diagonal field of view of 84°
- Location sonde (33 kHz / 512 Hz / 640 Hz)
- Up to 1 bar pressureproof
- Especially durable plastic hand drum
- Control unit with function keys to control the camera head
- Light regulation
- Anti-glare 5'' monitor
- BNC Video Out
- Meter counter
- Internal battery (5-7 hours)
- Color camera module; 0.02 Lux / F1.2; fix focus;
- 560 TV-lines; light ring with 12 pcs mini-LEDs, continuously adjustable, directly fixed to the push rod cable; cylindrical length 9 mm; spacer D = 24 mm
- 5" TFT LCD monitor with recorder function picture (*.jpg 640 x 480 pixel); video (MPEG4 *.avi 640 x 480 pixel)
- Storage medium: SD-card (max 32 GB)
- USB
- 3400 mA battery; wall power supply

Additional accessories available for the product, ask our sales team for more information.

12 months warranty

Made in Germany
