The Trelleborg Thermoliner Stretch SL is the ideal product for rehabilitating sections with dimensional changes and multiple bends of up to 90°.
Suitable for relining DN150 - DN225 (6'' - 9'') pipelines.
Its outstanding impregnation characteristics ensure easy handling and trouble-free installation, delivering high-quality results.
The PES nonwoven carrier material allows for installation with minimal pressure and excellent lining of bends. The special substrate material also enables overfilling the liner with resin, achieving superior final wall thicknesses in the expanded areas if required.
The Thermoliner Stretch SL is compatible with all known curing methods. When curing with steam, a temperature limit of 80 °C / 176 °F must be observed. At higher steam temperatures, a suitable calibration hose should be used to protect the hose from damage.
Due to its good stretchability, areas outside of the pipe must be protected against unwanted expansion using a preliner or calibration hose.

TECHNICAL FEATURES
Range of application: Underground- / Down pipes with diameter change
Pipe diameters: DN150 - DN225 (6'' - 9'')
Raw material thickness: Approx. 6.3 mm
Cured liner thickness: 4.5 mm
Roller gap: 10 mm
Epoxy consumption: 2.48 kg / m (17.94 lbs / ft)
Installation pressure: 0.3 bar (4.35 psi)
Installation pressure for larger diameter: 0.5 bar (7.25 psi)
Seam type: Sewn and taped (TPU)
Coating: Polyurethane (PU)
Diameter change: Max. 50 %
Temperature resistance: Up to 80 °C / 176 °F, up to 100 °C / 212 °F if cal tube is used
Curing: UV-Hg / LED, Ambient, Hot water and Steam
Properties: Very high radial expansion, liner must be protected against radial expansion with a calibration hose (inspection hatches, manholes, beginning and end, and other free spaces)
In accordance with global standards: DIN EN, DIBt, ASTM
Certified quality: DIN EN ISO 9001, DIN EN ISO 14001

Compatible with the following epoxy resins:
Boldan Oy: BDA / BD / BDA + / BX / BE / BF / BA / BC / B1
Trelleborg Pipe Seals GmbH: EPROPOX FC15 / EPROPOX FC30 / EPROPOX HC120 / RayCure 1k UV resin
SewerTronics™ Ep 1k epoxy resin

Package size 100 m / 328 ft - actual lengths may vary
